> It is the most appropriate machine used to cut feed plants growing aslope such as common vetch, white clover, bird-foot deervetch and any meadow, pasturage and weeds by the impact of air flow occurring by turning of discs.
> It has safety mechanism in order to prevent the damages to occur during hitting hard and large objects (tree, stone etc.).
> It is made appropriate to slope through a hydraulic piston in sloping land.
> The grasses cut are provided to be collected at desired width by a router inserted behind the machine.
> It spreads the grasses cut by high cutting quality as uniform stalk is left. By this means, high speed drying is performed by protecting plant nutrition values.
> It provides performing quite low and quality cutting in graded field.
| MODEL | A-RDM 04 | A-RDM 05 | A-RDM 06 |
|---|---|---|---|
| Number of Discs (pieces) | 4 | 5 | 6 |
| Working Width (mm) | 1626 | 2006 | 2386 |
| Transport Width (mm) | 1260 | 1260 | 1260 |
| Overall Height (mm) | 2390 | 2770 | 3150 |
| Number of Blades (pieces) | 8 | 10 | 12 |
| Optimal Working Speed | 5-6 | 5-6 | 5-6 |
| Capacity (da/h) | 6,5-8 | 8-10 | 10-12 |
| P.T.O. Shaft Rotations (max) (min-1) | 540 | 540 | 540 |
| Weight (kg) | 445 | 465 | 475 |
| Power Requirement (HP) | 40 | 50 | 60 |
Rotary Disc Mower Brochure
