> High resistible, heat treated discs notched at front and plain at rear or alternated.
> Transport tyres also ensure optimum working depth control.
> Ease and speed of set-up into the work/transport position.
> Easy gang angling adjustment with locking device standart manual or Hdroulic (Optional)
> Increased inter-disc spacing and disc scrapers preventing trash built up.
> Spacers and bearing housings made from steel for trouble free long working life.
| MODEL | CDHX20 | CDHX24 | CDHX28 |
|---|---|---|---|
| Number of Discs (pieces) | 20 | 24 | 28 |
| Disc Diameter (mm) | 610 | 610 | 610 |
| Disc Spacing (cm) | 23 | 23 | 23 |
| Working Width (cm) | 250 | 300 | 350 |
| Working Depth (cm) | 22 | 22 | 22 |
| Weight (kg) | 1660 | 1920 | 2120 |
| Power Requirement (HP) | 80-90 | 100-110 | 120-130 |
Trailed X Type Heavy Disc Harrow Brochure
