> Usually it is more appropriate to use where there is plenty of straw waste on the field.
> For disc type machines, fertilizer coulter are also produced with double-discs.
> Depth settings can be adjusted with the help of the wheels next to the planter disc, while pressure is applied with V-shaped pressure wheels at the rear of the unit. Also optionally a seed pressure wheel is attached to rear side of the planter discs for small and delicate seeds.
| MODEL | Eldorada 4 (disc coulter) | Eldorada 4 (disc coulter) | Eldorada 4 (disc coulter) | Eldorada 4 (disc coulter) | Eldorada 6 (tyne coulter) | Eldorada 6 (tyne coulter) |
|---|---|---|---|---|---|---|
| Chassis Width (m) | 3,9 | 4,5 | 6 | 3,9 | 4,5 | 6 |
| Number of planting units | 4 | 4 | 8 | 6 | 8 | 6 |
| Interrow distance, cm | 60-70-90 | 60-70-90 | 60-70-90 | 60-70-90 | 60-70-90 | 60-70-90 |
| Seed hoppers capacity, lt | 4x42 | 6x42 | 8x42 | 4x42 | 6x42 | 8x42 |
| Press Wheels | V-shaped press wheels, 325x50 mm | V-shaped press wheels, 325x50 mm | V-shaped press wheels, 325x50 mm | Big-diameter press wheels | Big-diameter press wheels | Big-diameter press wheels |
| Drive Wheels | 2 | 2 | 4 | 2 | 2 | 4 |
| Hydraulic Markers | + | + | + | + | + | + |
| Extra Press Wheel in the Row | + | + | + | - | - | - |
| Transport System | - | - | option | - | - | option |
| PTO Drive Transmission | 540 rpm | 540 rpm | 540 rpm | 540 rpm | 540 rpm | 540 rpm |
| Capacity (ha/h) | 2,8 | 4,2 | 5,6 | 2,8 | 4,2 | 5,6 |
| Fertiliser Hoppers Capacity (lt) | 2x300 (disc coulter for fertilisers) | 2x200 (disc coulter for fertilisers) | 4x220 (disc coulter for fertilisers) | 2x300 (tyne coulter for fertilisers) | 2x200 (tyne coulter for fertilisers) | 4x220 (tyne coulter for fertilisers) |
| Seeding Control System | + | + | + | + | + | + |
| Maximum Working Speed (km/h) | 10-12 | 10-12 | 10-12 | 10-12 | 10-12 | 10-12 |
| Ağırlık (kg) | 1500 | 1700 | 2300 | 1200 | 1200 | 1900 |
| Güç (HP) | 110+ | 80-100 | 120-150 | 90+ | 80-100 | 120-150 |
Pnömatik Ekim Makinesi Ürün Broşürü
