> 20-30 % fuel economy in comparison with mouldboard ploughs.
> Standard 660 mm or 710 mm optional discs made from Boron Steel with special concavity.
> 5 level disc penetration angle and 3 level disc position adjustment
> Adjustable disc position angle (vertical 3 positions, lateral 5 positions) for use in tough or soft soil conditions.
> Excellent solution for rooty, sticky or abrasive soil.
> Flanged frame to add an extension, if required.
> Adjustable and replaceable scrapers not only for cleaning also for overturning
> Heavy duty rear furrow wheel from hardened steel, spring loaded, full adjustable vertically and laterally, with additional cast weightenings.
> Steel Bearing housings to assure trouble free long operation life
> Adjustment arm for best tractor- plough alignment
| MODEL | DIP02 | DIP03 | DIP04 | DIP05 | DIP06 | DIPB03 | DIPB04 |
|---|---|---|---|---|---|---|---|
| Number of Discs (pieces) | 2 | 3 | 4 | 5 | 8 | 3 | 4 |
| Disc Diameter (mm) | 660 | 660 | 660 | 660 | 660 | 660 | 660 |
| Clearence (cm) | 68 | 68 | 68 | 68 | 68 | 68 | 68 |
| Working Width (cm) | 50-60-70 | 70-75-100 | 90-110-130 | 110-135-160 | 130-160-190 | 75 | 100 |
| Working Depth (cm) | 26 | 26 | 26 | 26 | 26 | 26 | 26 |
| Weight (kg) | 364 | 450 | 565 | 664 | 770 | 423 | 555 |
| Power Requirement (HP) | 40-50 | 50-60 | 60-80 | 80-90 | 90-110 | 50-60 | 60-80 |
