> High resistible, heat treated notched discs.
> Increased inter-disc spacing preventing trash built up.
> Hydrolic folding rear roller to reduce the transport length for easy and safe transportation. Maintenance-free high-quality bearing units.
> Durable stone safety release via rubber elements.
| MODEL | BDH 20 | BDH 24 | BDH 28 | BDH 32 | BDH 40 | BDH 44 | BDH 48 |
|---|---|---|---|---|---|---|---|
| Working Width (m) | 2,50 | 3,00 | 3,50 | 4,00 | 5,00 | 5,50 | 6,00 |
| Транспортная ширина (m) | 3,00 | 3,50 | 4,00 | 4,50 | 5,50 | 3,25 | 3,25 |
| Disc Diameter (mm) | 560/510 | 560/510 | 560/510 | 560/510 | 560/510 | 560/510 | 560/510 |
| Disc Spacing (mm) | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
| Расстояние между рядами дисков (mm) | 250 | 250 | 250 | 250 | 250 | 250 | 250 |
| Number of Discs (pieces) | 20 | 24 | 28 | 32 | 40 | 44 | 48 |
| Максимальная глубина обработки (диск ø 560 мм) (мм) | 165 | 165 | 165 | 165 | 165 | 165 | 165 |
| Масса (диск ø 560 мм), (кг) | 1 415 | 1 640 | 1 890 | 2 240 | 2 950 | 4 580 | 5 150 |
| Масса (диск ø 510 мм), (кг) | 1 391 | 1 611 | 1 856 | 2 201 | 2 911 | 4 527 | 5 092 |
| Power Requirement (HP) | 80-90 | 120 | 130-140 | 150 | 180 | 200 | 220 |
Upon the needs of customers we keep the right to make changes on the product specifications.
Compact Disc Harrow Brochure
