> Hyroulicly controlled transport Tyres
> High resistible, heat treated discs notched at front and plain at rear or alternated.
> Transport tyres also ensure optimum working depth control.
> Ease and speed of set-up into the work/transport position.
> Easy gang angling adjustment with locking device standart manual or Hdroulic (Optional)
> Increased inter-disc spacing and disc scrapers preventing trash built up.
> Spacers and bearing housings made from steel for trouble free long working life.
| MODEL | CDHLX20 | CDHLX24 | CDHLX28 | CDHLX32 | CDHLX36 |
|---|---|---|---|---|---|
| Number of Discs (pieces) | 20 | 24 | 28 | 32 | 36 |
| Disc Diameter (mm) | 510 | 510 | 510 | 510 | 510 |
| Disc Spacing (cm) | 19 | 19 | 19 | 19 | 19 |
| Working Width (cm) | 190 | 228 | 266 | 304 | 342 |
| Working Depth (cm) | 10 | 10 | 10 | 10 | 10 |
| Weight (kg) | 920 | 960 | 1020 | 1060 | 1120 |
| Power Requirement (HP) | 40-60 | 60-70 | 70-80 | 80-100 | 100-120 |
