Conventional Plough With Spring Safety
Conventional Plough With Spring Safety
Conventional Plough With Spring Safety
Conventional Plough With Spring Safety
> Non-stop trouble free plowing opportunity for stony, rooted and first time plowed lands.

> The two helical springs lets the swing out bodies re-enter the soil immediately.

> The spring pressures can be easily adjusted for each body to different soil conditions in order to obtain optimum release characteristics.

> Flanged frame to add an extension, if required.

> Mechanical or Hydroulic working width adjustment.
> Trash boards

> Shares with Reversible Points

> Mouldboard Extension

> Deflector

> Slatted Body

> Wing Coulter

> Metal Depth Wheel

> Bar Point Body

> F, X and V Type Mouldboard
MODELOP10OP11OP12OP13OP14OP16
Clearence (cm)707070707070
Distance Between Beams (cm)757575757575
Working Width (cm)25,527,53032,53537,5
Working Depth (cm)242426282830
Weight (kg) 2390400410414417430
Weight (kg) 3560575590592595610
Weight (kg) 4745750760763765770
Weight (kg) 5915917925935941950
Power Requirement (HP) 230-4030-4040-5040-5040-5050-60
Power Requirement (HP) 345-5050-5555-6055-6060-7070-80
Power Requirement (HP) 470-8070-8570-8570-8580-9080-90
Power Requirement (HP) 580-9085-9590-10090-10090-110100-110
When placing an order, add the number of furrows to the end of model code.
Upon the needs of customers we keep the right to make changes on the product specifications.
