> Specially alloyed steel casting legs unique designed to get the most convenient penetration angle for maximum efficiency.
> Opportunity to work different widths with adjustable legs.
> Reversible shares made of special steel and processed with heat treatment.
> Bolt secured legs.
> Strong main frame from 100x100mm for CP and 120x120mm for CPA model.
> Roller
| MODEL | CP 005 | CP 007 | CP 009 | CP 011 | CP 013 | CP 015 |
|---|---|---|---|---|---|---|
| Number of Tines (pieces) | 5 | 7 | 9 | 11 | 13 | 15 |
| Clearence (cm) | 62 | 62 | 62 | 62 | 62 | 62 |
| Distance Between Beams (cm) | 30 | 30 | 30 | 30 | 30 | 30 |
| Working Width (cm) | 150 | 210 | 270 | 330 | 390 | 450 |
| Working Depth (cm) | 45 | 45 | 45 | 45 | 45 | 45 |
| Weight (kg) | 328 | 418 | 516 | 689 | 790 | 900 |
| Power Requirement (HP) | 50-60 | 60-80 | 80-90 | 90-100 | 100-110 | 120-140 |
| MODEL | CPA 05 | CPA 07 | CPA 09 | CPA 11 | CPA 13 | CPA 15 |
| Number of Tines (pieces) | 5 | 7 | 9 | 11 | 13 | 15 |
| Clearence (cm) | 74 | 74 | 74 | 74 | 74 | 74 |
| Distance Between Beams (cm) | 30 | 30 | 30 | 30 | 30 | 30 |
| Working Width (cm) | 150 | 210 | 270 | 330 | 390 | 450 |
| Working Depth (cm) | 60 | 60 | 60 | 60 | 60 | 60 |
| Weight (kg) | 550 | 725 | 880 | 1060 | 1240 | 1450 |
| Power Requirement (HP) | 70-80 | 80-90 | 90-110 | 110-130 | 130-150 | 150-170 |
Chissel Plough Brochure
